| Product Model | H3C UniServer R4700 G5 |
|---|---|
| Product Generation | 5th Gen Edge Computing Server |
| Form Factor | 1U Rackmount Design |
| Processor Model | Intel Xeon Gold 6348 Processor |
| Core Count | 28 Cores |
| Thread Count | 56 Threads |
| Base Frequency | 2.60GHz |
| Max Turbo Frequency | 3.50GHz |
| L3 Cache | 42MB |
| Max CPU Support | 2 Processors |
| Memory Capacity | 192GB DDR4 |
| Memory Type | DDR4 3200MHz RDIMM |
| Memory Slots | 32 DIMM Slots |
| Max Memory Support | 8TB |
| Storage Type | Hybrid Storage Configuration |
| Total Capacity | 12TB |
| Drive Configuration | 4×2TB NVMe SSD + 4×1TB SAS HDD |
| Hot-swap Support | Full Hot-swap Design |
| RAID Support | Hardware RAID 0,1,5,6,10,50,60 |
| Network Controller | Dual-port 25Gb OCP NIC |
| Network Ports | 2×SFP28 Ports |
| PCIe Slots | 5 PCIe 4.0 Slots |
| Slot Configuration | 3×x16, 2×x8 |
| Management Module | HDM Intelligent Operations Platform |
| Remote Management | Out-of-Band Management and Redfish Support |
| Power Supply Specification | 1200W Platinum Level High Efficiency Power Supply |
| Power Redundancy | 1+1 Redundancy Configuration Support |
| Product Dimensions | 43.8mm × 437mm × 785mm |
| Product Weight | 20.5kg |
| Supported Systems | Ubuntu Linux, Windows IoT, Red Hat Edge |
| Operating Temperature | -5℃ to 55℃ Wide Temperature Operation |
| Shock Resistance | MIL-STD-810G Military Standard |
Engineer's Note: The H3C UniServer R4700 G5 is a 1U Rackmount Design rack platform built around Intel Xeon Gold 6348 Processor, with support for up to 192GB of DDR4 3200MHz RDIMM. It is sized for high-performance computing and AI training nodes where memory capacity is as decisive as raw compute.
1. Compute density: 28 cores per processor, built on Intel Xeon Gold 6348 Processor. In a consolidated environment, per-socket core count determines how many VMs or containers each node can absorb before scheduling contention appears. Sizing the compute tier correctly the first time avoids the classic trap of overbuying "just in case" and paying for idle silicon.
2. 1U Rackmount Design form factor: the chassis height sets the expansion budget — full-height PCIe slots for GPUs and HCAs, and drive bays for local boot or cache tiers. It determines how the platform evolves over its 5–7 year service life.
3. Networking: Dual-port 25Gb OCP NIC. East-west traffic between nodes is usually the first bottleneck in scaled-out clusters; matched NIC capacity keeps compute fed and failover paths instant.
4. Storage architecture: RAID via Hardware RAID 0,1,5,6,10,50,60. The controller and bay layout decide whether the box becomes an all-NVMe compute node or a capacity-oriented storage server. Either way, hot-swap carriers mean drive replacements happen without downtime.
5. Memory subsystem: up to 192GB, DDR4 3200MHz RDIMM, 32 DIMM slots. Large memory footprints keep in-memory databases and VM farms off disk-based swap, which is often the single biggest lever on latency. Populating DIMM slots in matched sets also unlocks full interleaving bandwidth.
When the requirement is high-performance computing and AI training nodes, the H3C UniServer R4700 G5 is engineered so no single subsystem bottlenecks the rest. 192GB of memory headroom absorbs dataset growth, the storage layer protects data integrity, and the management plane keeps operational overhead flat as you scale. Each unit is fully tested before dispatch, and our team supports bulk deployments with configuration guidance and consolidated pricing.
Q: What management features does it include?
A: The platform includes an out-of-band management controller (remote console, health telemetry, firmware updates) standard on this generation, so hardware can be administered without an OS or a site visit.
Q: Do you offer bulk pricing for multi-unit orders?
A: Yes — cluster deployments and multi-unit orders receive consolidated pricing and coordinated logistics. Request a quote with your target quantity for a same-week response.
Q: Is it new or refurbished? What warranty applies?
A: Both new and fully tested refurbished units are available; condition is shown on the listing. All servers ship with a one-year warranty and have been stress-tested (compute, memory, storage, and thermal) before dispatch.
Q: Which rails and rack accessories do I need?
A: The server requires model-matched rail kits for your rack type (round-hole, square-hole, or threaded). Confirm your rack specification when ordering — we can include the correct rail kit and cable management arm.
Q: Can this server be shipped internationally?
A: Yes, we ship worldwide with export-compliant packaging. Transit insurance and appropriate power cables for your region are included on request.
