| item | value |
|---|---|
| Product Type | Enterprise Server |
| Form Factor | 1U Rackmount |
| Model | FusionServer 1288H V5 |
| CPU Model | Intel Xeon Silver 4214 2.2GHz |
| Cores | 12 Cores 24 Threads |
| Standard CPU Qty | 2 Processors |
| Max CPU Qty | 2 Processors |
| L3 Cache | 16.5MB |
| Memory Type | DDR4 RDIMM |
| Memory Capacity | 128GB |
| Memory Speed | 2933MT/s |
| Memory Slots | 24 DIMM Slots |
| Max Memory | 3TB(with 128GB modules) |
| Drive Configuration | 4×1.8TB SAS 10K 2.5" |
| Drive Interface | SAS 12Gbps |
| Max Drives | 10×2.5" drives |
| RAID Controller | SR430C-M 1GB Cache |
| RAID Levels | 0,1,5,6,10,50,60 |
| Onboard NIC | 2×10GE + 2×GE |
| PCIe Slots | Up to 5 PCIe 3.0 slots |
| PSU Type | 550W Platinum AC Power |
| PSU Qty | 2 Redundant PSUs |
| PSU Redundancy | 1+1 Redundancy |
| Management Chip | iBMC Dedicated Chip |
| Management Features | Fault Diagnosis, Auto O&M |
| Management Interfaces | Redfish, SNMP, IPMI 2.0 |
| Dimensions(H×W×D) | 43×436×708mm |
| Weight | Approx. 18kg |
| Operating Temperature | 5℃-45℃ |
| Operating Humidity | 8%-90% |
| Warranty | 3 Years Limited |
