| item | value |
|---|---|
| Design Philosophy | Cloud-Native Optimized Server |
| Model Number | 1288H V5-CN |
| Product Series | Cloud Infrastructure Series |
| Chassis Design | 1U High-Density Design |
| Chassis Material | Galvanized Steel + Aluminum Alloy |
| Processor Model | Intel Xeon Platinum 8368 |
| Core Architecture | Ice Lake-SP Architecture |
| Core Count | 38 Cores 76 Threads |
| Base Frequency | 2.4GHz |
| Max Turbo Frequency | 3.4GHz |
| L3 Cache | 57MB |
| Memory Technology | DDR4-3200 ECC RDIMM |
| Memory Capacity | 512GB(16×32GB) |
| Memory Bandwidth | 204.8GB/s(per processor) |
| Memory Protection | Advanced ECC, Address Parity |
| Storage Type | All-NVMe U.2 Configuration |
| Storage Capacity | 8×3.84TB NVMe SSD |
| Interface Protocol | NVMe 1.4 |
| Read/Write Performance | Sequential Read 7000MB/s |
| IOPS Performance | Random Read 1M IOPS |
| Network Controller | Dual 100GbE CX6 DX |
| Network Technology | RoCEv2, SR-IOV, RDMA |
| Latency Optimization | Ultra-Low Latency Network Stack |
| Storage Acceleration | Intel QuickAssist Technology |
| Data Compression | Hardware-Accelerated Data Compression |
| PCIe Version | PCIe 4.0 |
| Expansion Slots | 5 PCIe 4.0 x16 Slots |
| Power Specification | 2000W Platinum High Efficiency |
| Power Management | Dynamic Power Capping Technology |
| Energy Efficiency | 96% Platinum Efficiency |
| Cooling Solution | Intelligent Liquid Cooling Ready |
| Fan Control | AI-based Predictive Fan Control |
| Secure Boot | UEFI Secure Boot |
| Hardware Root of Trust | Hardware-based Root of Trust |
| Firmware Protection | Firmware Attack Protection |
| Cloud Management | Native Kubernetes Support |
| API Interface | Comprehensive RESTful API Support |
| Monitoring Capability | Real-time Telemetry Data Collection |
| Energy Optimization | Complies with Climate Neutral Pledge |
| Material Usage | 95% Recyclable Materials |
| Operating Temperature | 10°C to 40°C |
| Noise Level | <75 Decibels |
| Green Certification | ENERGY STAR 8.0 |
| Cloud-Native Apps | Containerized Workload Optimized |
| Big Data | Real-time Data Analytics Processing |
