| item | value |
|---|---|
| Product Line | xFusion Enterprise Server Series |
| Model | 1288H V5 |
| Generation | V5 Series |
| Chassis Height | 1U Rackmount |
| Chassis Depth | Standard Depth |
| Processor Model | Intel Xeon Platinum 8260 |
| Base Frequency | 2.4GHz |
| Core Count | 24 Cores 48 Threads |
| Turbo Frequency | 3.9GHz |
| Processor Quantity | 2 Processors |
| Memory Type | DDR4-2933 ECC RDIMM |
| Memory Capacity | 192GB(12×16GB) |
| Memory Slots | 24 DDR4 DIMM Slots |
| Max Memory | 3TB(using 128GB LRDIMM) |
| Storage Type | NVMe SSD U.2 |
| Drive Capacity | 8×1.92TB NVMe SSD |
| Interface Type | NVMe 3.0 x4 |
| Max Storage Capacity | 10×2.5" Drives |
| RAID Controller | High-performance RAID Card 4GB Cache |
| RAID Support | 0,1,5,6,10,50,60,NVMe RAID |
| Network Controller | Dual 25GbE SFP28 + Dual 10GbE SFP+ |
| Network Interfaces | 2×25G SFP28, 2×10G SFP+ |
| PCIe Slots | 5 PCIe 3.0 Slots |
| Expansion Slots | 3×FHFL, 2×FHHL |
| Power Supply | 1200W Platinum High Efficiency |
| PSU Quantity | 2 Hot-swap Redundant PSUs |
| PSU Efficiency | 94% Platinum Certified |
| Management Controller | Intelligent Management Chip |
| Management Interfaces | Redfish, IPMI 2.0, SNMP |
| Remote Management | Out-of-band Management, KVM over IP |
| Dimensions | 43.5×438×756mm |
| Net Weight | Approx. 19.8kg |
| Operating Temperature | 5°C to 40°C |
| Storage Temperature | -40°C to 65°C |
| Operating Humidity | 8% to 90% Non-condensing |
| Safety Certification | CE, FCC, RoHS, TUV |
| Warranty Period | 3 Years Limited Warranty |
| Optimized Workloads | AI, Machine Learning, HPC |
