item | value |
---|---|
Brand | Samsung |
Series | PM9A3 Series |
Model / Part Number | MZQL2960HCJR-00W07 |
Capacity | 960GB |
Flash Type | 3D TLC V-NAND |
Workload Type | Mixed Use |
Interface | PCIe 4.0 x4 NVMe 1.4 |
Form Factor | 2.5-inch U.2 |
Sequential Read Speed | Up to 6,900 MB/s |
Sequential Write Speed | Up to 3,500 MB/s |
Random Read IOPS (4K) | 1,200,000 IOPS |
Random Write IOPS (4K) | 200,000 IOPS |
Endurance (DWPD) | 1.5 DWPD (5 years) |
Endurance (TBW) | 2.63 PBW |
MTBF | 2 million hours |
Hardware Encryption | AES-256 bit |
Security Standards | TCG Opal 2.0, TCG Pyrite |
Power Loss Protection | Yes |
Operating Temperature | 0°C to 70°C |
Power Consumption (Active) | 7.5W |
Power Consumption (Idle) | 4.0W |
Write Latency | 10µs |
Read Latency | 70µs |
Application | Virtualization Platforms, Database Servers, Enterprise Applications, High Performance Computing Nodes |
