| item | value |
|---|---|
| Product Certification | Original Genuine Made in China |
| Product Condition | Brand New Sealed |
| Product Model | ThinkSystem SR860 V3 |
| Product Series | V3 Enterprise Series |
| Manufacturing Origin | Shenzhen, China |
| Form Factor | 4U Rack Mount |
| Processor Platform | 4th Gen Intel Xeon Scalable |
| Processor Sockets | 4x LGA4677 Sockets |
| Max Processors | 4 Processors |
| Max Cores | 240 Cores |
| Memory Type | DDR5-4800 RDIMM |
| Memory Slots | 96 DIMM Slots |
| Max Memory | 12TB |
| Memory Protection | ECC Error Correction |
| Controller Standard | SAS-4 24Gb |
| Drive Interface | SAS4/SATA/NVMe |
| Max Drives | Up to 48x 2.5" |
| RAID Configuration | Hardware RAID 0,1,5,6,10,50,60 |
| PCIe Standard | PCIe 5.0 |
| Expansion Slots | Up to 28 PCIe Slots |
| Network Controller | OCP 3.0 NIC |
| Network Speed | 100/200GbE Optional |
| Management System | XClarity Controller Enterprise |
| Management Features | Out-of-Band,REST API |
| Security Chip | TPM 2.0 Encryption Module |
| Secure Boot | UEFI Secure Boot |
| Power Configuration | Dual Hot-swap Redundant PSU |
| Power Efficiency | 80 PLUS Titanium |
| Input Voltage | 200-240V AC |
| Cooling Technology | Intelligent Vector Cooling |
| Fan Configuration | 8x Hot-swap Fans |
| Chassis Dimensions | 175×447×800mm |
| Net Weight | 65kg |
| Supported OS | Windows Server 2022,RHEL,SLES |
| Virtualization Support | VMware vSphere,Hyper-V |
