| Processor Series | Intel Xeon Scalable Processors |
|---|---|
| Supported Generations | 2nd to 4th Generation |
| Processor Sockets | 4x LGA Sockets |
| Cores per Processor | 8-60 Cores Optional |
| Hyper-Threading | Hyper-Threading Support |
| Turbo Boost | Up to 4.4GHz |
| L3 Cache | Up to 105MB |
| Memory Type | DDR4-3200 (V2)/DDR5-4800 (V3) |
| Max Memory | 6TB (V2)/12TB (V3) |
| Memory Channels | 8 Channels per CPU |
| Error Correction | ECC Error Correction Code |
| Controller Type | SAS-3 12Gb (V2)/SAS-4 24Gb (V3) |
| Interface Standard | SAS/SATA/NVMe |
| Max Drives | Up to 48x 2.5" |
| RAID Levels | 0,1,5,6,10,50,60 |
| PCIe Version | PCIe 4.0 (V2)/PCIe 5.0 (V3) |
| PCIe Slots | Up to 20 (V2)/28 (V3) |
| Network Controller | OCP 3.0 NIC |
| Network Speed | 10/25/100GbE Optional |
| Management System | XClarity Controller |
| Remote Management | Redfish API Support |
| Security Chip | TPM 2.0 Security Module |
| Secure Boot | UEFI Secure Boot |
| Power Configuration | Hot-swap Redundant PSU |
| Power Efficiency | 80 PLUS Platinum Certified |
| Rated Power | 1600W Redundant PSU |
| Cooling Technology | Intelligent Vector Cooling |
| Fan Configuration | N+1 Redundant Fans |
| Chassis Dimensions | 175×447×800mm |
| Product Weight | Max 85kg |
| Supported OS | Windows Server, Linux, VMware |
| Virtualization Support | VMware, Hyper-V, Xen |
| Performance Features | NUMA Architecture Optimization |
| Application Scenarios | AI, Machine Learning, Big Data Analytics |
Engineer's Note: The Intel Xeon Processors Lenovo SR860 V2/V3 is a 4U rack platform built around current-generation scalable compute, with a scalable memory subsystem. It is sized for virtualization consolidation and private cloud hosts where memory capacity is as decisive as raw compute.
1. Networking: OCP 3.0 NIC. East-west traffic between nodes is usually the first bottleneck in scaled-out clusters; matched NIC capacity keeps compute fed and failover paths instant.
2. 4U form factor: the chassis height sets the expansion budget — full-height PCIe slots for GPUs and HCAs, and drive bays for local boot or cache tiers. It determines how the platform evolves over its 5–7 year service life.
3. Storage architecture: RAID via 0,1,5,6,10,50,60. The controller and bay layout decide whether the box becomes an all-NVMe compute node or a capacity-oriented storage server. Either way, hot-swap carriers mean drive replacements happen without downtime.
4. Lifecycle economics: enterprise servers depreciate over 5+ years, and the Intel Xeon Processors Lenovo SR860 V2/V3 is designed for that horizon — serviceable components, firmware support, and spare parts availability. Buying through the refurbished channel shifts the cost curve down without shortening the useful life.
5. Deployment fit: the Intel Xeon Processors Lenovo SR860 V2/V3 is typically deployed as virtualization consolidation and private cloud hosts. Its subsystem balance — compute, memory, storage, and networking in proportion — is what separates a purpose-built node from a general-purpose box that excels at nothing.
When the requirement is virtualization consolidation and private cloud hosts, the Intel Xeon Processors Lenovo SR860 V2/V3 is engineered so no single subsystem bottlenecks the rest. the storage layer protects data integrity, and the management plane keeps operational overhead flat as you scale. Each unit is fully tested before dispatch, and our team supports bulk deployments with configuration guidance and consolidated pricing.
Q: What management features does it include?
A: The platform includes an out-of-band management controller (remote console, health telemetry, firmware updates) standard on this generation, so hardware can be administered without an OS or a site visit.
Q: Does it come with an OS installed?
A: Units ship hardware-tested without an OS by default. We can pre-install common enterprise Linux distributions or VMware ESXi on request — specify your preference in the quote form.
Q: Can this server be shipped internationally?
A: Yes, we ship worldwide with export-compliant packaging. Transit insurance and appropriate power cables for your region are included on request.
Q: What is the power draw I should plan for?
A: Plan per the configured PSU rating plus headroom: a fully populated system can draw near the PSU maximum under load. For datacenter provisioning, size PDUs on max configured wattage, not idle draw.
Q: Which rails and rack accessories do I need?
A: The server requires model-matched rail kits for your rack type (round-hole, square-hole, or threaded). Confirm your rack specification when ordering — we can include the correct rail kit and cable management arm.
