Intel SSDPE2KX080T8 8 TB DC P4510 PCIe 3.1 x4, NVMe 2.5 inch 15mm Enterprise Solid State Drive

General

Brand	Intel
Model	DC P4510
Capacity	8 TB
Usage Class	Enterprise

Interface

Host Interface	PCIe 3.1 x4, NVMe
Total Interface Bandwidth	32 Gb/s

Physical Dimension

Form Factor	2.5 inch 15mm

Flash & Endurance

NAND Flash	64-layer 3D TLC
Drive Writes Per Day	1
Total Bytes Written	13880 TBW

Performance

Sequential Read	3200 MB/s
Sequential Write	3000 MB/s
Random Read IOPS	637000
Random Write IOPS	139000
Average Latency	10 μs

Reliability

Mean Time Between Failures	2 Million Hours
Uncorrectable Bit Error Rate	1.0×10⁻¹⁷
Power Loss Protection	Yes

Part Number

MPN	SSDPE2KX080T7

Engineer's Note

Compared with the previous-generation SSDPE2KX080T7, the SSDPE2KX080T8 DC P4510 advances to 64-layer 3D TLC and delivers a denser 8 TB PCIe 3.1 x4 NVMe platform with up to 3200/3000 MB/s throughput and 637K/139K IOPS for faster, higher-capacity scale-out storage nodes. With 1 DWPD and 13,880 TBW endurance, it is a strong fit for read-intensive cloud, virtualization, and analytics deployments that need more usable capacity per drive without giving up enterprise-class reliability.

Endurance & Reliability

With an endurance rating of 13,880 TBW and 1 DWPD, the SSDPE2KX080T8 is built to handle sustained enterprise write workloads over its service life. In practical terms, for typical server, storage, or system-disk use, this level of endurance provides long-term write headroom and can comfortably support many years of stable operation without endurance concerns. The drive also includes enterprise-class reliability features such as Power Loss Protection (PLP), which helps protect in-flight data and metadata during unexpected power interruptions. Its ultra-low UBER of 1.0E-17, together with a 2 million hour MTBF, indicates a very low probability of unrecoverable read errors and strong overall dependability for business-critical environments.

Technical Specs & Insights

1. The PCIe 3.1 x4 NVMe architecture gives this drive a low-overhead, parallel data path that helps enterprise servers accelerate storage access and reduce CPU bottlenecks versus legacy SAS or SATA SSDs.
2. Its strong sequential read performance enables much faster movement of large datasets, making it well suited for analytics platforms, media repositories, backup restores, and VM image loading.
3. The high random read capability allows the SSD to sustain heavy transaction concurrency, which is critical for virtualization clusters, OLTP databases, and read-intensive cloud workloads.
4. With a 1 DWPD endurance class, it fits mainstream enterprise deployments that need dependable full-capacity rewrites every day, such as mixed-use servers and scale-out infrastructure.
5. Built on 64-layer 3D TLC NAND and backed by very low typical latency, the drive balances density, cost efficiency, and responsive QoS for business applications that demand predictable storage behavior.

Endurance & Reliability

Lower capacity reference: 4 TB Higher capacity reference: 16 TB At 8 TB, the SSDPE2KX080T8 sits at the sweet spot of this enterprise SSD family. Compared with the 4 TB model, it gives much more headroom for VM growth, log retention, and mixed application datasets without increasing drive count. Compared with the 16 TB option, it keeps acquisition cost, rebuild exposure, and per-node storage budgeting under better control while delivering essentially the same enterprise-class sequential and random performance profile. It is especially well suited for mid-size virtualization clusters, such as hosting boot and primary data volumes for about 40 to 60 business application VMs.
