| Brand | Intel |
|---|---|
| Model | DC S3610 |
| Capacity | 1.6 TB |
| Usage Class | Enterprise/Mixed-Use |
| Host Interface | SATA 6Gb/s |
|---|---|
| Total Interface Bandwidth | 6 Gb/s |
| Form Factor | 2.5 inch 7mm |
|---|
| NAND Flash | 20nm MLC |
|---|---|
| Drive Writes Per Day | 3 |
| Total Bytes Written | 10700 TBW |
| Sequential Read | 540 MB/s |
|---|---|
| Sequential Write | 500 MB/s |
| Random Read IOPS | 84000 |
| Random Write IOPS | 27000 |
| Average Latency | 55 μs |
| Mean Time Between Failures | 2 Million Hours |
|---|---|
| Uncorrectable Bit Error Rate | 1.0×10⁻¹⁷ |
| Power Loss Protection | Yes |
| MPN | SSDSC2BX016T4 |
|---|
Compared with the previous SSDSC2BX016T4, the SSDSC2BX016T4R is the lifecycle-refresh choice for data-center SATA deployments, offering a lower-risk continuity path while sustaining the same enterprise-grade 1.6 TB, 3 DWPD endurance profile and 10.7 PBW class that operators depend on. Its combination of 20nm MLC NAND, 540/500 MB/s sequential throughput, and 84K/27K IOPS makes it a particularly strong fit for read-intensive virtualization, CDN cache, and mixed OLTP workloads that need higher write endurance and steadier QoS than typical value SATA SSDs.
With an endurance rating of 10,700 TBW and 3 DWPD, the SSDSC2BX016T4R is built for sustained write-intensive enterprise workloads over its service life. In practical terms, for typical server or system-disk usage, this level of endurance provides ample headroom for many years of reliable operation without concern about normal write wear. The drive also includes power-loss protection (PLP), which helps preserve in-flight data and metadata during an unexpected power interruption, reducing the risk of corruption and improving system integrity. Combined with an enterprise-class UBER of 1.0E-17 and a 2 million hour MTBF, it delivers a very low probability of uncorrectable errors and strong overall dependability for business-critical environments.
1. The SATA 6Gb/s interface, paired with near-bus-limit sequential read performance, makes this drive a practical drop-in upgrade for enterprise servers that need fast data streaming without changing existing backplanes or controllers.
2. Its strong random read capability helps virtualized databases, metadata-heavy applications, and boot-intensive server workloads respond faster under mixed-user access patterns.
3. A 3 DWPD endurance rating means it is built for write-intensive enterprise duty cycles, supporting sustained daily rewrites with lower replacement risk across its service life.
4. The 20nm MLC NAND provides a balanced combination of endurance, performance consistency, and cost efficiency that is well suited to mainstream data center deployments.
5. Typical latency in the tens of microseconds helps reduce storage wait time for transactional workloads, improving application responsiveness and tail-latency behavior in busy environments.
Lower capacity reference: 1.2 TB Higher capacity reference: 1.92 TB At 1.6 TB, this SSD sits in the sweet spot of the family. Compared with the 1.2 TB model, it provides more room for VM growth, OS images, logs, and spare capacity while keeping the same enterprise-class SATA performance profile. Compared with the 1.92 TB version, it avoids the final cost step-up while delivering nearly identical real-world throughput and latency for mainstream server workloads. It is best suited to mid-scale deployments, such as a 6 to 8 node virtualization cluster or a 200 to 300 seat VDI pool.
Q: Is SSDSC2BX016T4R suitable for a write-heavy database server?
A: Yes. SSDSC2BX016T4R is well suited for write-intensive database workloads, thanks to 3 DWPD endurance, 10,700 TBW, 20nm MLC NAND, low 55 µs latency, and enterprise-grade reliability features.
Q: How many full drive writes per day can it actually endure over its warranty period?
A: This model is rated for 3 full drive writes per day. With 1.6 TB capacity, that equals about 4.8 TB of writes daily across its defined warranty period.
Q: Does it include power loss protection (PLP) and why is that critical?
A: Yes, it includes power loss protection. PLP helps preserve in-flight data and metadata during unexpected outages, reducing corruption risk and improving data integrity in enterprise storage environments.
Q: What RAID level is recommended for this SSD?
A: RAID recommendation depends on workload. For database servers, RAID 10 is commonly preferred for strong performance and redundancy. RAID 1 suits smaller deployments, while RAID 5/6 prioritizes capacity.
