| Brand | Samsung |
|---|---|
| Model | 9100 PRO |
| Capacity | 1 TB |
| Usage Class | Client |
| Host Interface | PCIe Gen3 x4 |
|---|---|
| Total Interface Bandwidth | 32 Gb/s |
| Form Factor | M.2 (2280) |
|---|
| NAND Flash | Samsung V-NAND 3D TLC |
|---|---|
| Drive Writes Per Day | 0.3 |
| Total Bytes Written | 600 TBW |
| Sequential Read | 3500 MB/s |
|---|---|
| Sequential Write | 3300 MB/s |
| Random Read IOPS | 600000 |
| Random Write IOPS | 550000 |
| Average Latency | 100 μs |
| Mean Time Between Failures | 1.5 Million Hours |
|---|---|
| Uncorrectable Bit Error Rate | 1.0×10⁻¹⁷ |
| Power Loss Protection | No |
| MPN | MZ-V7P1T0BW |
|---|
The Samsung 9100 PRO 1TB (MZ-VAP1T0B/AM) delivers a clear generational performance uplift over MZ-V7P1T0BW, raising sequential write speed from 2,700 to 3,300 MB/s while improving random performance to 600,000/550,000 IOPS for faster compile, scratch, and mixed workstation workloads. Built on Samsung V-NAND 3D TLC, it preserves top-end PCIe Gen3 x4 read bandwidth at 3,500 MB/s while offering a more balanced performance-per-terabyte profile for professional desktops that need 600 TBW endurance without moving to a higher-cost platform.
With an endurance rating of 600 TBW, the MZ-VAP1T0B/AM can sustain about 164 GB of host writes per day for 10 years, or over 300 GB per day for 5 years, which is comfortably above the needs of a typical OS, office, and application drive. In practical terms, for normal client and light business workloads, this level of endurance provides long service life with ample write headroom and supports the 0.3 DWPD rating. For reliability, the drive is specified at a 1.0E-16 UBER, meaning unrecoverable read errors are extremely rare and data integrity is maintained at a level appropriate for mainstream commercial deployments, supported by a 1.5 million-hour MTBF rating. It does not include onboard power-loss protection (PLP), so it is best deployed in systems with stable power, UPS coverage, or application-level safeguards if protection against sudden power interruption during writes is required.
1. The PCIe Gen3 x4 host link gives this drive enough bandwidth to keep virtualization clusters, boot storms, and analytics nodes fed without the bottlenecks common to legacy SATA SSDs.
2. Its strong sequential read capability accelerates large-file streaming, database snapshot recovery, and data-lake scans, helping reduce job start times in read-heavy enterprise workloads.
3. The high random read performance is well suited for OLTP databases, VDI farms, and metadata-intensive applications where fast access to many small blocks directly improves user responsiveness.
4. With a light-write endurance profile, this SSD fits best in read-centric deployments such as content delivery, scale-out web tiers, and query-heavy reporting systems rather than intensive logging or write-cache roles.
5. Samsung V-NAND 3D TLC paired with low typical latency delivers a practical balance of density, power efficiency, and consistently quick access, enabling predictable SLA behavior in mixed enterprise environments.
Lower-capacity reference: 960 GB Higher-capacity reference: 1.92 TB Capacity positioning analysis: In this SSD family, the 1 TB model sits at the practical sweet spot. Compared with the 960 GB option, it gives operators a bit more headroom for OS growth, patching, logs, container layers, and overprovisioning flexibility, reducing the risk of early capacity pressure. Compared with the 1.92 TB version, it preserves essentially the same enterprise-class sequential and random I/O behavior while keeping acquisition cost and fleet standardization more manageable. It is especially well suited for mid-scale virtualization clusters, such as hosting boot and application volumes for about 40 to 60 mixed-workload virtual machines.
Q: Is MZ-VAP1T0B/AM suitable for a write-heavy database server?
A: Not ideally. With 0.3 DWPD, 600 TBW, TLC NAND, and no PLP, this model is better for read-intensive or mixed workloads than sustained write-heavy database server environments.
Q: How many full drive writes per day can it actually endure over its warranty period?
A: It is rated for 0.3 full drive writes per day. For a 1 TB SSD, that means about 300 GB of writes daily on average during the warranty period.
Q: Does it include power loss protection (PLP) and why is that critical?
A: No, it does not include PLP. PLP is critical because it helps protect in-flight data and metadata during sudden power failure, reducing corruption risk in enterprise workloads.
Q: What RAID level is recommended for this SSD?
A: RAID 1 or RAID 10 is generally recommended for this SSD, depending on capacity and performance needs. These levels provide redundancy and are better suited for business-critical data protection.
