| item | value |
|---|---|
| Market Positioning | Telecom Grade Edge Computing Server |
| Model Number | 1288H V5-TC |
| Product Edition | Telecom Enhanced Edition |
| Chassis Type | 1U Short Depth Chassis |
| Mounting Depth | 600mm Depth Rack Compatible |
| Processor Model | Intel Xeon Gold 6348 |
| Process Technology | 10nm SuperFin |
| Core Count | 28 Cores 56 Threads |
| Base Frequency | 2.6GHz |
| Max Turbo Frequency | 3.5GHz |
| TDP | 235W |
| Memory Type | DDR4-3200 ECC RDIMM |
| Memory Capacity | 384GB(12×32GB) |
| Memory Bandwidth | 204.8GB/s |
| Error Correction | ECC, DDDC, SDDC |
| Primary Storage | 8×800GB SAS SSD 12Gbps |
| Cache Storage | 4×800GB NVMe SSD |
| Storage Interface | Dual-port SAS3.0 |
| Hot Swap | Supports Front Hot-swap |
| Data Protection | End-to-end Data Protection |
| Network Controller | Intel XXV710 Dual 25GbE |
| Additional NIC | Intel X550 Dual 10GbE |
| Network Features | SR-IOV, RDMA Support |
| Cooling Solution | Intelligent Adaptive Cooling |
| Liquid Cooling | Rear Door Heat Exchanger Ready |
| Fan Design | N+1 Redundant Fan Design |
| Power Specification | 1600W DC Power Supply |
| Power Input | 48V DC Input |
| Power Redundancy | 1+1 Redundant Configuration |
| Availability | 99.999% Availability |
| MTBF | 150,000 Hours |
| Security Certification | TNC Security Architecture Certified |
| Hardware Security | Trusted Platform Module 2.0 |
| Management Interface | Redfish-based RESTful API |
| Remote Management | Out-of-band Management Support |
| Supported OS | Wind River Linux, Yocto |
| Virtualization | KVM Virtualization Support |
| Operating Temperature | -5°C to 55°C |
| Operating Humidity | 5% to 95% |
| Industry Certification | NEBS Level 3, ETSI |
| Environmental Certification | RoHS, REACH |
| Primary Applications | 5G Edge Computing, NFV |
| Secondary Applications | IoT Gateway, CDN |
